Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
158 01/2017
Call Conditions
Subroutine Name
Description
Each scan (SM0.0) PI_SERVICE (SBR46) ASUP (Asynchronous Subroutine Pro-
gram)
Each scan (SM0.0)
ServPlan (SBR48)
Maintenance plan example: first task
Each scan (SM0.0)
Turret1_HED_T (SBR51)
HALL effect device turret control
Each scan (SM0.0)
Tail_stock_T (SBR55)
Tailstock control
Each scan (SM0.0)
Lock_unlock_T (SBR56)
Clamp or release control
Each scan (SM0.0)
MM_MAIN (SBR58)
Manual machine
Each scan (SM0.0) MM_MCP_808D (SBR59) Spindle signal processing for the man-
ual machine
Each scan (SM0.0)
Trg_key_OR (SBR62)
Override control
6.4.2
PLC sample application (milling)
This sample application is applicable to machines with the following configurations:
● Three axes: axes X, Y and Z, with a hardware limit switch respectively in the positive and negative directions of each axis
● A spindle: SP (the fourth axis)
● PLC-controlled timely and quantitatively lubrication system
● PLC-controlled cooling system
Assignment of inputs and outputs
Signal
Description
Remark
I0.0
Emergency Stop button
Normally closed
I0.1 Limit switch in the "+" direction of axis X Normally closed
I0.2
Limit switch in the "-" direction of axis X
Normally closed
I0.3
Limit switch in the "+" direction of axis Y
Normally closed
I0.4
Limit switch in the "-" direction of axis Y
Normally closed
I0.5
Limit switch in the "+" direction of axis Z
Normally closed
I0.6
Limit switch in the "-" direction of axis Z
Normally closed
I0.7
Reference point switch of axis X
Normally open
I1.0
Reference point switch of axis Y
Normally open
I1.1
Reference point switch of axis Z
Normally open
I1.2
Disk-style tool magazine: tool magazine count
Valid at a low level
I1.3
Disk-style tool magazine: tool magazine at the spindle position
Valid at a low level
I1.4
Disk-style tool magazine: tool magazine at the original position
Valid at a low level
I1.5
Disk-style tool magazine: tool at the release position
Valid at a low level
I1.6
Disk-style tool magazine: tool at the clamping position
Valid at a low level
I1.7
-
Reserved
I2.0
-
Reserved
I2.1
-
Reserved
I2.2 - Reserved
I2.3
-
Reserved
I2.4
Coolant level too low
Normally closed
I2.5
Cooling pump motor overload
Normally closed
I2.6
Lubricant level too low
Normally closed
I2.7
Lubrication pump motor overload
Normally closed
I3.0 - Reserved
I3.1
-
Reserved
