Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
456 01/2017
17.11.4
User alarm: Configuring (MD 14516 USER_DATA_PLC_ALARM)
DB4500
Signals from NCK [r8]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
3000
Alarm response/cancel criteria, alarm 700000
3001
Alarm response/cancel criteria, alarm 700001
3002
Alarm response/cancel criteria, alarm 700002
...
...
3247
Alarm response/cancel criteria, alarm 700247
Note
For more information about how to configure user alarms, see Section "
Editing PLC alarm texts (Page 231)".
17.12
Signals, synchronized actions
17.12.1
Signals, synchronized actions to channel
DB4600
Signals, synchronized actions to channel [r/w]
PLC -> HMI interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Deactivate synchronized action with ID...
ID8
ID7
ID6
ID5
ID4
ID3
ID2
ID1
1
Deactivate synchronized action with ID...
ID16
ID15
ID14
ID13
ID12
ID11
ID10
ID9
2
Deactivate synchronized action with ID...
ID24
ID23
ID22
ID21
ID20
ID19
ID18
ID17
17.12.2
Signals, synchronized actions from channel
DB4700
Signals, synchronized actions from channel [r]
NCK -> PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Synchronized action with ID...can be blocked from the PLC
ID8
ID7
ID6
ID5
ID4
ID3
ID2
ID1
1
Synchronized action with ID...can be blocked from the PLC
ID16 ID15 ID14 ID13 ID12 ID11 ID10 ID9
2
Synchronized action with ID...can be blocked from the PLC
ID24
ID23
ID22
ID21
ID20
ID19
ID18
ID17
17.12.3
Reading and writing PLC variables
DB4900
PLC variables [r/w]
PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Offset [0]
1
Offset [1]
2
Offset [2]
…
…
4094
Offset [4094]
4095
Offset [4095]
