Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
266 01/2017
11.
Use these softke
ys to switch to the data set for axis MY1.
12.
Use
this softkey or the cursor keys to search for the drive parameter p29000. Enter the motor
ID of the motor connected to axis MY1. You can find the motor ID on the motor rating plate.
13.
Press this softkey to activate the value changes. Note that the control system restarts to a
c-
cept the new values.
14.
I
f necessary, you can also tune the drive performance for the Y axis. For more information,
see Section "
Tuning the drive performance (Page 259)". Note that you must perform the refer-
ence point approach for the Y axis first before you start the drive tuning.
12.2.2
Measuring the tool manually (with the Y axis)
Note
This section takes the milling tool measurement as an example.
Measuring the X axis of the tool
1.
Select the machining operating area.
2.
Switch to "MDA" mode and enter "SPOS=0" in the progr
am editor window to fix the spindle.
→
3.
Switch to handwheel control mode.
4.
Select a suitable override feedrate.
5.
Use the handwheel to move the tool to approach the workpiece and cut the surface of the
workpiece for about 1 mm along the Y axis. Then ret
ract the tool along the Y axis.
Note:
Make sure you do not move the tool along the X axis afterwards.
6.
Switch to "MDA" mode and continue to enter "SPOS=180" in the program editor window.
7.
Press this key to rotate the spindle 180 degrees.
8.
Repeat Steps 3 to 5.
9.
Measure the distance between the two cutting surfaces machined in the previous steps with
a calliper.
10.
Select the offset operating ar
ea.
11.
Press the alphabetic key <X> or proceed through the following method to open the window
for measuring the tool in the X direction:
