Commissioning Manual
484 01/2017
To cut a reserved hole, proceed as follows:
Customizing pre-defined labeling strips for keys of the MCP
Note
The horizontal MCP with a reserved slot for the handwheel is designed for turning machines only. The customization of the
pre
-defined labeling strips for keys is not supported by this MCP variant.
The MCP strips of the turning version are already pre-assembled into the MCP. If you are using the control system of milling
version, you need to take these pre-defined labeling strips out firstly, and then insert the MCP strips of the milling version
delivered in MCP package into the MCP.
To insert the MCP strips, follow the order shown as follows with reference to the marks (M1 to M6, T1 to T6) on the strips:
To Next Page
