Technical data
15.1
SINUMERIK 808D/SINUMERIK 808D ADVANCED
Horizontal PPU
(161.3/141.2)
Vertical PPU
(160.2)
Horizontal MCP
Vertical MCP
Design data
Dimensions (W × H × D, mm) 420 × 200 × 95
1)
/104
2)
265 × 330 × 104 420 × 120 × 58
3)
/38
4)
265 × 230 × 58
Gross weight (kg)
3.95/3.9
3.85
1.05
3)
/0.76
4)
1.2
5)
/1.1
6)
Net weight (kg)
3.0
3.0
0.7
3)
/0.41
4)
0.75
5)
/0.65
6)
Cooling method
Self-cooling
Degree of protection Front: IP65
Rear: IP20
Front: IP65
Rear: IP00
Electrical data
Supply voltage 24 V DC (permissible range: 20.4 V to
28.8 V)
5 V DC powered by PPU
Mains buffering time
3 ms
-
Ripple 3.6 Vpp -
Current consumption from 24 V
1.5 A (I/O open)
-
Rated input current
2 A
0.5 A
Power consumption
Max. 50 W
Max. 5 W
Humidity rating in accordance with
EN 60721-3-3
Class 3K5, condensation and icing excluded; low air temperature 0 °C
Overvoltage category
3
Degree of pollution
2
Transport and storage conditions
Temperature
-20 °C to +60 °C
Vibration resistance (transport) 5 Hz to 9 Hz: 3.5 mm
9 Hz to 200 Hz: 1g
Shock resistance (transport) 10 g peak value, 6 ms duration
100 shocks in each of the 3 axes vertical to one another
Free fall
< 1 m
Relative humidity
5% to 95%, without condensation
Atmospheric pressure
1060 hPa to 700 hPa (corresponds to an altitude of 3000 m)
Ambient operating conditions
Temperature Front: 0 °C to 45 °C
Rear: 0 °C to 50 °C
Relative humidity
5% to 90%, without condensation
Atmospheric pressure
From 1080 hPa to 795 hPa
