Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
384 01/2017
Horizontal PPU
(161.3/141.2)
Vertical PPU
(160.2)
Horizontal MCP
Vertical MCP
Vibration resistance (in operation) 10 Hz to 58 Hz: 0.35 mm
58 Hz to 200 Hz: 1g
Shock resistance (in operation) 10 g peak value, 6 ms duration
6 shocks in each of the 3 axes vertical to each other
Certification
CE, KC
7)
, and EAC
CE and EAC
1)
For PPU161.3;
2)
For PPU141.2;
3)
For the horizontal MCP with override switches;
4)
For the horizontal MCP with a reserved slot for the handwheel;
5)
For the vertical MCP with an override switch for the spindle;
6)
For the vertical MCP with a reserved slot for the handwheel;
7)
The KC certification is valid for the PPU161.3 only.
15.2
Servo drives
15.2.1
SINAMICS V70 feed drives
Frame size
FSA
FSB
FSC
Order No.
6SL3210-5DE...
12-4UA0
13-5UA0
16-0UA0
17-8UA0
21-0UA0
21-4UA0
21-8UA0
Rated output current
1.2 A
3.0 A
4.6 A
5.3 A
7.8 A
11.0 A
13.2 A
Max. output current
3.6 A
9.0 A
13.8 A
15.9 A
23.4 A
33.0 A
39.6 A
Max. supported motor power
0.4 kW
1.0 kW
1.5 kW
1.75 kW
2.5 kW
3.5 kW
7.0 kW
Output frequency
0 Hz to 330 Hz
Power supply
Voltage/frequency
3 phase 380 VAC to 480 VAC, 50/60 Hz
Permissible voltage fluctu-
ation
-15% to +10%
Permissible frequency
fluctuation
-10% to +10%
Rated input current
1.5 A
3.8 A
5.8 A
6.6 A
9.8 A
13.8 A
16.5 A
Power supply capacity
1.7 kVA
4.3 kVA
6.6 kVA
7.6 kVA
11.1 kVA
15.7 kVA
18.9 kVA
Inrush current
8.0 A
8.0 A
4.0 A
4.0 A
4.0 A
2.5 A
2.5 A
Power loss
1)
Main circuit 31 W 32 W 76 W 90 W 96 W 115 W 138 W
Control circuit
32 W
32 W
35 W
35 W
35 W
36 W
36 W
Built-in regenerative resis-
tor
57 W 57 W 131 W 131 W 131 W 339 W 339 W
Total
120 W
121 W
242 W
256 W
262 W
490 W
513 W
24 VDC power
supply
Voltage 24 V (-15% to +20%)
Exception: When the SINAMICS V70 works with a motor with brake, the
voltage tolerance of 24 VDC power supply must be -10% to +10% to meet
the voltage requirement of the brake.
Maximum current 1 A (when using a motor without a brake)
3 A (when using a motor with a brake)
