Commissioning Manual
01/2017
505
Configuring the remote control
With the remote control function you can perform the following operations:
● Operating the HMI remotely from a computer
● Generating screenshots of the HMI and saving them onto a computer
Note
To use the remote control function of AMM, make sure you enable the communication ports 22 and 5900 on the HMI. For
more information about enabling the communication ports, see Section "
Configuring the firewall (Page 43)".
Configuring the remote access rights
Proceed through the following steps to configure the remote access rights on the HMI:
Select the alarm operating area on the PPU.
Press this softkey to change the settings, if desired.
Press this softkey to make the settings changeable. Note that this softkey is visible only with a
s
ystem password.
Use this key to select the desired right for remote access. You can choose to allow the remote
operation/monitoring of the HMI, or forbid the remote access to the HMI.
Set the behavior of the control system when it receives a remote access request.
Specify the duration of the following dialog box displaying on the HMI:
The following operations on the HMI are possible when this dialog box appears:
Press this softkey to reject the request.
Press this softkey to permit the request.
