Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
01/2017
17
2
Preparation before commissioning
2.1
Scope of delivery
2.1.1
SINUMERIK 808D ADVANCED control system
2.1.1.1
System overview
The SINUMERIK 808D ADVANCED control system is an economic numerical control system for milling or turning machines.
The SINUMERIK 808D ADVANCED controller, coupled with the high performance SINAMICS V70 feed/spindle drive,
SIMOTICS S-1FL6 feed motor, and SIMOTICS M-1PH1 main motor, is able to control up to five axes including analog/digital
spindles.
Control system versions
Control system
SINUMERIK 808D ADVANCED T
SINUMERIK 808D ADVANCED M
Applicable machine tools
Turning machines
Milling machines
PPU
PPU variants
PPU161.3
PPU160.2
PPU161.3
PPU160.2
Applicable software ver-
sion
V4.7.4 V4.7.4 V4.7.4 V4.7.4
Panel layout
Horizontal
Vertical
Horizontal
Vertical
Operator panel with Eng-
lish keys
√ √ √ √
Operator panel with Chi-
nese keys
√ √ √ √
MCP Configurable MCPs are available in the following versions:
• Horizontal MCP, with English keys and override switches
• Horizontal MCP, with Chinese keys and override switches
• Horizontal MCP, with Chinese keys and a reserved slot for the handwheel (applicable to turning ma-
chines only)
• Vertical MCP, with English keys and a reserved slot for the handwheel
• Vertical MCP, with Chinese keys and a reserved slot for the handwheel
• Vertical MCP, with English keys and an override switch for the spindle
•
Vertical MCP, with Chinese keys and an override switch for the spindle
Number of
configurable
axes
Total
Up to 5
Up to 5
Standard axes
3
3
4
4
Additional axes (license
required)
2 2 1 1
Communication with drive
Drive Bus interface
Drive Bus interface
Configurable drives
SINAMICS V70 feed/spindle drive
SINAMICS V70 feed/spindle drive
Configurable motors SIMOTICS S-1FL6/SIMOTICS M-
1PH1
SIMOTICS S-1FL6/SIMOTICS M-
1PH1
√: available
