Siemens SINUMERIK 808D Commissioning Manual

Commissioning Manual
01/2017
435
...
User data
126
User data
127
17.5
User Alarms
17.5.1
User alarms: Activating
DB1600
Activating alarm [r/w]
PLC -> HMI interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Activation of alarm no.
700007
700006
700005
700004
700003
700002
700001
700000
1
Activation of alarm no.
700015
700014
700013
700012
700011
700010
700009
700008
2
Activation of alarm no.
700023
700022
700021
700020
700019
700018
700017
700016
3
Activation of alarm no.
700031
700030
700029
700028
700027
700026
700025
700024
4
Activation of alarm no.
700039
700038
700037
700036
700035
700034
700033
700032
5
Activation of alarm no.
700047
700046
700045
700044
700043
700042
700041
700040
...
...
15 Activation of alarm no.
700127
700126
700125
700124
700123
700122
700121
700120
17.5.2
Variables for user alarms
DB1600
Variables for user alarms [r32/w32]
PLC -> HMI interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
DBD1000 Variable for alarm 700000
DBD1004
Variable for alarm 700001
DBD1008 Variable for alarm 700002
…
…
DBD1500
Variable for alarm 700125
DBD1504
Variable for alarm 700126
DBD1508
Variable for alarm 700127
