Working in manual mode
4.5 Manual retraction
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
117
After an interruption of a tapping operation (G33/G331/G332) or a general drilling operation
(tools 200 to 299) due to power loss or a RESET at the machine control panel, you have the
possibility to retract the tool in the JOG mode in the tool direction without damaging the tool
or the workpiece.
The retraction function is especially useful when the coordinate system is swiveled, i.e. the
infeed axis is not in the vertical position.
Note
Tapping
In the case of tapping, the form fit between the tap and the workpiece is taken
into account
and the spindle moved according to the thread.
The Z axis as well as the spindle can be used for retraction at the thread.
The "Retraction" function must be set up by the machine manufacturer.
Please refer to the machine manufacturer's specifications.
<RESET> interrupts the power supply to the m
achine and any running
After a power supply interruption, switch on the controller.
Select the JOG operating mode.
Press the Menu forward key.
Press the "Retract" softkey.
The "Retract Tool" window opens.
The softkey is available only when an active tool and retraction data are
present.
Select the "WCS" coordinate system on the machin
e control panel.
Use the traversing keys (e.g. Z +) to traverse the tool from the wor
k-
ce according to the retraction axis displayed in the "Retract Tool"
e window, press the "Retract" softkey again when the tool is at
To Next Page
