Programming technology functions (cycles)
9.6 Further cycles and functions
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
563
Tool
- (only for G
code)
Tool tip position when swiveling
Tracking
The position of the tool tip is maintained during
swiveling.
No tracking
The position of the tool tip changes during swiveling.
Swiveling tool (CYCLE800)
9.6.2.1
Aligning turning tools - only for G code program (CYCLE800)
Function
The "Align turning tool" and "Align milling tool" functions support combined turning-milling
machines with a B axis that can be swiveled.
In contrast to "Swivel plane", no rotation is operative in the active work offsets in the
workpiece coordinate system in the case of "Align tool". Only the offsets calculated by the
NC and the corresponding tool orientation are effective.
The maximum angular range for "Align tool" is +/- 360 degrees or it is limited by the
traversing range of the participating rotary axes. Technological limits are also placed on the
angular range depending on the tool used. When aligning the tool, the data of the tool is
calculated based on the tool orientation using the CUTMOD NC command. For a turning
tool, the calculation involves the cutting edge position, the holder angle and the cut direction.
Definition of the β and γ angles
The beta and gamma angles orientate the turning tools. They refer to the WCS. If the WCS
corresponds to the MCS, the tool data remains unchanged for β=0° / γ=0° (cutter position,
holder angle, ...).
The definition of angles beta and gamma depends on the particular machine. In the initial
state of the machine kinematics for turning, a turning tool can be orientated according to Z or
X.
Please refer to the machine manufacturer's specifications.
