Working in manual mode
4.7 Thread synchronizing
Turning
120 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Machining
direction
• Face
• Longitudinal
Reference point ∅ (abs)
End point X ∅ (abs) or end point X in relation to X0 (inc)
End point Z (abs) or end point Z in relation to X0 (inc)
FS1...FS3 or R1...R3
Chamfer width (FS1...FS3) or rounding radius (R1...R3) mm
Undercut (alternative to FS2 or R2)
Infeed depth (inc) – (for roughing only)
Final machining allowance in X direction (inc) – (for roughing only)
Final machining allowance in Z direction (inc) – (for roughing only)
Tool, offset value, feedrate and spindle speed (T, D, F, S, V) (Page 254)
If you wish to re-machine a thread, it may be necessary to synchronize the spindle to the
existing thread turn. This is necessary as by reclamping the blank, an angular offset can
occur in the thread.
Thread synchronizing is not possible if a toolcarrier is used (B axis).
Note
Activating/deactivating thread synchronization
If a thread synchronization is active, then this is active for all of the following "Thread turning"
machining steps.
Thread synchronization remains effective without deactivation even after the machining has
been shutdown.
The spindle is stationary.
One threading tool is active.
