Siemens SINUMERIK 828D User Manual

Easy Message (828D only)
21.6 Displaying SMS logs
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
875
21.6
Displaying SMS logs
The SMS data traffic is recorded in the "SMS Log" window. In this way, it is possible to see
the chronological sequence of activates when a fault occurs.
Symbols
Description
Incoming SMS message for the Messenger.
Message that has reached the Messenger, but which has not been
processed (e.g. incorrect user ID or unknown account).
SMS message sent to a user.
Message that has not reached the user because of an error.
Requirement
The connection has been established to the modem.
Procedure
1.
Press the "SMS log" softkey.
The "S
MS Log" window appears.
All the messages that have been sent or received by the Messe
n
ger are
listed.
Note
Press the "Incoming" or "Outgoing" softkey to restrict the list.
