Siemens SINUMERIK 828D User Manual

Tool management
12.5 Tool list
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
683
12.5.1
Additional data
The following tool types require geometry data that is not included in the tool list display.
Tool types with additional geometry data
Tool type
Additional parameters
111 Conical ballhead cutter
Corner radius
121 End mill with corner round-
ing
Corner radius
130 Angle head cutter Geometry length (length X, length Y, length Z)
Wear length (Δ length X, Δ length Y, Δ length Z)
Adapter length (length X, length Y, length Z)
V (direction vector 1 - 6)
Vector X, vector Y, vector Z
131 Angle head cutter with
corner rounding
Geometry length (length X, length Y, length Z)
Corner radius
Wear length (Δ length X, Δ length Y, Δ length Z)
Adapter length (length X, length Y, length Z)
V (direction vector 1 - 6)
Vector X, vector Y, vector Z
140 Face milling External radius
Tool angle
155 Bevel cutter
Taper angle
156 Bevel cutter with corner
rounding
Corner radius
Taper angle
157 Conical die-milling cutter
Taper angle
700 slotting saw Geometry length (length X, length Y, length Z)
Wear length (Δ length X, Δ length Y, Δ length Z)
Adapter length (length X, length Y, length Z)
Geometry (slot width, projection)
Wear (slot width, projection)
You can use the configuration file to specify the data to be displayed for specific tool types in
the "Additional Data" window.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
