Alarm, error and system messages
14.7 Version
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
797
All the machine-specific information of the control is combined in a configuration via the user
interface. You can save machine-specific information on the drives that have been set-up.
the "Diagnostics" operating area.
Press the "Version" softkey.
call the version display. While the version data is
being determined a progress message box and the appropriate text are
displayed in the dialog line.
Press the "Save" softkey.
The "Save Version Information: Select Archive" window opens. The
following storage locations are offered depending on the configur
ation:
Local drive
Network drives
USB
Version data (archive: Data tree in the "HMI data" directory)
rectory" softkey if you wish to create your own
Press the "OK" softkey. The
directory is created.
Press the "OK" softkey again to confirm the storage location.
The "Save Version Information: Name" window opens. The following
options are available:
In the "Name:" text field, the file name is pre-
name/no.>+<CF-card number>. "_config.xml" or "_version.txt" is
automatically attached to the file names.
In text field "Comment", you can add a comment that is stored with
the configuration data.
Select the following data via a checkbox:
Version data (.TXT): Output of pure version data in text format.
Configuration data (.XML): Output of configuration data in XML
format. The configuration file contains the data you entered under
Machine identity, the license requirements, the version information
and the logbook entries.
Press the "OK" softkey to start the data transfer.
