Setting up the machine

3.8 Zero offsets

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

3.8.3

Displaying and editing base zero offset

The defined channel-specific and global base offsets, divided into coarse and fine offsets,

are displayed for all set-up axes in the "Zero offset - Base" window.

Machine manufacturer

Please refer to the machine manufacturer's specifications.

Procedure

Select the "Parameter" operating area.

Press the "Zero offset" softkey.

Press the "Base" softkey.

The "Zero Offset

- Base" window is opened.

You can edit the values directly in the table.

Note

Activate base offsets

The offsets specified here are immediately active.
