Machining the workpiece

5.7 Starting machining at a specific point

Turning

138 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

Note

Search mode for ShopTurn programs

•

The search variant for the ShopTurn machining step programs can be specified via MD

51024. This applies only to the ShopTurn single-channel view.

Machine manufacturer

Please refer to the machine manufacturer's specifications.

References

For additional information, please refer to the following documentation:

SINUMERIK Operate (IM9) / SINUMERIK 840D sl Commissioning Manual

Procedure

Select the "Machine" operating area.

Press the <AUTO> key.

Press the "Block search" and "Bloc

k search mode" softkeys.

The "Search Mode" window opens.
