Machining the workpiece

5.9 Overstore

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

143

Note

Block-by-block execution

The <SINGLE BLOCK> key is also active in the overstore mode. If several blocks are

entered in the overstore buffer, then these are executed block

-by-block after each NC start

Deleting blocks

Press the "Delete blocks" softkey to delete program blocks you have

entered.
