Siemens SINUMERIK 828D User Manual

Creating a G code program
7.6 Blank input
Turning
224 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
ZC3 Chuck dimension of the counterspindle - (only for spindle chuck data "yes" and for a
counterspindle that has been set up)
mm
ZS3 Stop dimension of the counterspindle - (only for spindle chuck data "yes" and for a coun-
terspindle that has been set up)
mm
ZE3 Jaw dimension of the counterspindle with jaw type 2 - (only for spindle chuck data "yes"
and for a counterspindle that has been set up)
mm
XR3 Tailstock diameter - (only for spindle chuck data "complete" and tailstock that has been
set up)
mm
ZR3 Tailstock length - (only for spindle chuck data "complete" and tailstock that has been set
up)
mm
XA
Outside diameter – (only for tube and cylinder)
mm
XI
Inside diameter (abs) or wall thickness (inc) – (only for tube)
mm
N
Number of edges – (only for polygon)
SW or L
Width across flats or edge length – (only for polygon)
mm
W
Width of the blank - (only for centered cuboid)
mm
L
Length of the blank - (only for centered cuboid)
mm
