Creating a ShopTurn program
8.16 Programming the approach/retraction cycle
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
271
Table 8- 1
Parameters
Description
Unit
F1
Feedrate to approach the first position
Alternatively, rapid traverse
mm/min
X1
1. position ∅ (abs) or 1st position (inc)
mm (in)
Z1
1. position (abs or inc)
mm
F2 Feedrate for approach to the second position
Alternatively, rapid traverse
mm/min
X2
2. position ∅ (abs) or 2nd position (inc)
mm
Z2
2. position (abs or inc)
mm
F3
Feedrate to approach the third position
Alternatively, rapid traverse
mm/min
X3
3. position ∅ (abs) or 3rd position (inc)
mm
Z3
3. position (abs or inc)
mm
Tool change
TlChngPt
: Approach the tool change point from the last programmed position and
carry out a tool change
direct
: Tool is not changed at the tool change position, but at the last programmed
position
No: Tool is not changed
T
Tool name - (only for "direct" tool change)
D
Cutting edge number - (only for "direct" tool change)
F4
Feedrate for approach to the fourth position
Alternatively, rapid traverse
mm/min
X4
4. position ∅ (abs) or 4th position (inc)
mm
Z4 4. position (abs or inc) mm
F5
Feedrate to approach the fifth position
Alternatively, rapid traverse
mm/min
X5 5. position ∅ (abs) or 5th position (inc) mm
Z5
5. position (abs or inc)
mm
F6 Feedrate to approach the sixth position
Alternatively, rapid traverse
mm/min
X6
6. position ∅ (abs) or 6th position (inc)
mm
Z6
6. position (abs or inc)
mm
