Siemens SINUMERIK 828D User Manual

Creating a ShopTurn program
8.18 Example: Standard machining
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
275
X1
-1.6
abs
Z1
0
abs
D
2
inc
UX
0
inc
UZ
0.1
inc
5.
Press the "Accept" sof
tkey.
3. Input of blank contour with contour computer
1.
Press the "Cont. turn." and "New contour" softkeys.
The "New Contour" input window opens.
2.
Enter the contour name (in t
his case: Cont_1).
The contour calculated as NC code is written as internal subprogram
between a start and an end marker containing the entered name.
3.
Press the "Accept" softkey.
The "Starting point" entry field opens.
4.
Enter the starting point of the contour.
X
60
abs
Z
0
abs
5.
Press the "Accept" softkey.
6.
Enter the following contour elements and acknowledge using the "A
c-
cept" softkey.
6.1
Z
-
40
abs
6.2
X
80
abs
Z
-
45
abs
6.3
Z
-
65
abs
6.4
X
90
abs
Z
-
70
abs
6.5
Z
-
95
abs
6.6
X
0
abs
