Programming technology functions (cycles)
9.1 Drilling
Turning
300 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
Position
(only for ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
(only for ShopTurn)
Clamp/release spindle
The function must be set up by the machine manufacturer.
Drilling depth
• Shank (drilling depth in relation to the shank)
The drill is inserted into the workpiece until the drill shank reaches the value pro-
grammed for Z1. The angle entered in the tool list is taken into account.
• Tip (drilling depth in relation to the tip)
The drill is inserted into the workpiece until the drill tip reaches the value pro-
grammed for Z1.
Note:
If it is not possible to define an angle for the drill in the tool management, it will
not be possible to select tip or shank (always tip, 0 field).
Z0 (only for G
code)
Reference point Z mm
Z1 Drilling depth (abs) or drilling depth in relation to Z0 (inc).
It is inserted into the workpiece until it reaches Z1.
DT Dwell time at final drilling depth s
rev
Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can
be adjusted using setting data.
Parameter
Description
Value
Can be set in SD
PL (only for G
code)
Machining plane
Defined in MD
52005
SC (only for G
code)
Safety clearance 1 mm x
Predrilling
ZA
Predrilling depth
FA
Reduced predrilling feedrate
Through drilling
ZD
Depth for reduced feedrate
FD
Reduced through drilling feedrate
Machine manufacturer
Please refer to the machine manufacturer's specifications.
