Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.1 Drilling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
311
Parameter
Description
Position (only for
ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
Clamp/release spindle
The function must be set up by the machine manufacturer.
Z1 Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1.
D - (only for G
code)
1. Drilling depth (abs) or 1st drilling depth in relation to Z0 (inc) mm
D - (only for Shop-
Turn)
Maximum depth infeed mm
Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can
be adjusted using setting data.
Parameter
Description
Value
Can be set in SD
PL (only for G
code)
Machining plane Defined in MD
52005
SC (only for G
code)
Safety clearance 1 mm x
Drilling depth
Drilling depth in relation to the tip
Tip
FD1
Percentage for the feedrate for the first infeed
90 %
x
DF Percentage for each additional infeed (for swarf removal
only)
90 % x
V1
Minimum infeed
1.2 mm
x
V2
Retraction distance after each machining step
1.4 mm
x
Clearance distance
The clearance distance is calculated by the cycle
Automatic
DBT (only for G
code)
Dwell time at drilling depth 0.6 s x
DT
Dwell time at final drilling depth
0.6 s
x
DTS (only for G
code)
Dwell time for swarf removal (for swarf removal only) 0.6 s x
Machine manufacturer
Please refer to the machine manufacturer's specifications.
