Programming technology functions (cycles)
9.2 Rotate
Turning
356 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Please also refer to the machine manufacturer's instructions.
If the tool does not round the corner at the end of the cut, it is raised by the safety distance
or a value specified in the machine data at rapid traverse. The cycle always observes the
lower value; otherwise, stock removal at inner contours, for example, could cause the
contour to be damaged.
Please also refer to the machine manufacturer's instructions.
● Finishing
Finishing is performed in the same direction as roughing. The cycle automatically selects
and deselects tool radius compensation during finishing.
1. The tool first moves at rapid traverse to the starting point of the machining operation
calculated internally in the cycle (reference point + safety distance).
2. The tool moves to the first infeed depth at rapid traverse.
3. The first cut is made at machining feedrate.
4. The tool rounds the contour at machining feedrate or is raised at rapid traverse (see
"Roughing").
5. The tool is moved at rapid traverse to the starting point for the next infeed depth.
6. The next cut is made at machining feedrate.
7. Steps 4 to 6 are repeated until the final depth is reached.
8. The tool moves back to the safety distance at rapid traverse.
The part program or ShopTurn program to be processed has been cr
e-
ated and you are in the editor.
Press the "Turning" softkey.
Press the "Stock removal"
softkey.
The "Stock Removal" input window opens.
Select one of the three stock removal cycles via the softkeys:
Simple straight stock removal cycle.
The "Stock removal 1" input window opens.
