Programming technology functions (cycles)

9.3 Contour turning

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

401

Press the "Calculate" softkey.

- OR -

Press the <INPUT> key.

The new value is calculated and displayed in the entry field of the calc

lator.

Press the "Accept" softkey.

The calculated value is accepted and displayed in the entry field of

the

window.

Rejecting entries

Press the "Delete" softkey to reject your entries.
