Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.3 Contour turning
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
421
Procedure
1.
The part program or ShopTurn program to be processed has been cr
e-
ated and you are in the editor.
2.
Press the "Contour turning" softkey.
3.
Press the "Grooving residual material" softkey.
The "Grooving residual material" input window is opened.
Parameters, G code program
Parameters, ShopTurn program
PRG
Name of the program to be generated
T
Tool name
PL
Machining plane
D
Cutting edge number
RP Retraction plane – (only for
longitudinal machining di-
rection)
mm F Feedrate mm/rev
SC Safety clearance mm S / V
Spindle speed or constant
cutting rate
rpm
m/min
F
Feedrate
*
CON
Name of the updated blank contour for residual
material machining (without the attached char-
acter "_C" and double-digit number)
Residual
material
With subsequent residual material removal
• Yes
• No
CONR Name to save the updated unmachined-part
contour for residual material removal - (only
"Yes" for residual material removal)
