Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.7 Additional cycles and functions in ShopTurn
Turning
590 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Enter the positioning angle for the CP machining area if you selected
machining plane face Y.
- OR -
Enter reference point C0 if you selected the machining plane peripheral
surface Y.
- OR -
Choose whet
her the spindle should be clamped or released or whether
there should be no change (input field left blank).
Press the "Accept" softkey.
The values are saved and the window is closed. The process plan is
displayed and the newly generated program block is marked.
Parameters
Description
Unit
T
Tool name
D
Cutting edge number
S1 / V1 Spindle speed or
constant cutting rate
rpm
m/min
Plane selection Select between the following machining surfaces:
• Peripheral surface/Peripheral C
• Peripheral surface Y - only if there is a Y axis
• Face/Face C
• Face Y - only if there is a Y axis
• Turning
∅
Diameter of the cylinder (for peripheral surface/peripheral surface C)
mm
C0 Positioning angle for machining area (for peripheral surface Y) Degrees
CP
Positioning angle for machining area (for face Y)
Degrees
