Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.7 Additional cycles and functions in ShopTurn
Turning
596 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameters
Description
Unit
Direction of rotation Direction of rotation in which the tool travels from the circle starting point to the
circle end point
Direction of rotation clockwise (right)
Direction of rotation counterclockwise (left)
Y
Z
Machining plane peripheral surface/peripheral surface C
Target position Y (abs) or target position X referred to the last programmed posi-
tion (inc)
Target position Z (abs) or target position Y referred to the last programmed posi-
tion (inc)
Note:
Incremental dimension: The sign is also evaluated
mm
mm
Y
Z
Machining plane, peripheral surface Y
Target position Y (abs) or target position X referred to the last programmed posi-
tion (inc)
Target position Z (abs) or target position Y referred to the last programmed posi-
tion (inc)
Note:
Incremental dimension: The sign is also evaluated.
mm
mm
X
Y
Machining plane face/face C
Target position X (abs) or target position X referred to the last programmed posi-
tion (inc)
Target position Y (abs) or target position Y referred to the last programmed posi-
tion (inc)
Note:
Incremental dimension: The sign is also evaluated
mm
mm
X
Y
Machining plane face Y
Target position X (abs) or target position X referred to the last programmed posi-
tion (inc)
Target position Y (abs) or target position Y referred to the last programmed posi-
tion (inc)
Note:
Incremental dimension: The sign is also evaluated.
mm
mm
X
Z
Machining plane rotation
Target position X ∅ (abs) or target position Y referred to the last programmed
position (inc)
Target position Z (abs) or target position X referred to the last programmed posi-
tion (inc)
Note:
Incremental dimension: The sign is also evaluated.
mm
mm
R Radius of circular arc
The sign determines the type of arc traversed.
mm
mm
F Machining feedrate. mm/rev
mm/min
mm/tooth
