Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.7 Additional cycles and functions in ShopTurn
Turning
608 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
Unit
Machining side
function
Machining Selection of the spindle for machining:
• Main spindle
Machining on the main spindle
• Counter-spindle
Machining on the counter-spindle
Work offset Work offset in which the coordinate system, which was shifted according to ZW
and by ZV as well as mirrored in Z, must be saved:
• Basic reference
• G54
• G55
• G56
• G57
• ...
Write to the
work offset
• Yes
The Z value of the work offset can be directly written to the input screen form.
• No
The actual Z value of the work offset is used.
ZV - only for work off-
set write "yes"
• Offset Z = 0 (abs)
• Workpiece zero is offset in Z direction (inc, the sign is also evaluated)
mm
Park counter-spindle -
for machining with main
spindle
• Yes
The counter-spindle is traversed to the park position.
• No
The counter-spindle is not traversed.
Z4P - for machining
with main spindle
Park position of the counter-spindle (abs); MCS mm
Z4W - for machining
with counter-spindle
Machining position of the counter-spindle (abs); MCS mm
