Multi-channel machining
10.2 Multi-channel support
Turning
660 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameters
Description
Unit
Synchronization function
Synchronizes with the counter-spindle in the other channel.
Coordinate
system
• MCS
The park position is specified in the machine coordinate system. Teaching
in the park position and angular offset is only possible in the machine coor-
dinate system.
• Workpiece coordinate system
The park position is specified in the workpiece coordinate system.
XP
Park position of tool in X direction (abs)
mm
ZP Park position of tool in Z direction (abs) mm
Complete transfer
function
Gripping
Coordinate
system
• MCS
The park position is specified in the machine coordinate system. Teaching
in the park position and angular offset is only possible in the machine coor-
dinate system.
• WCS
The park position is specified in the workpiece coordinate system.
XP
Park position of tool in X direction (abs)
mm
ZP
Park position of tool in Z direction (abs)
mm
Flush chuck Flush counter-spindle chuck
• Yes
• No
DIR Direction of rotation
•
Spindle rotates clockwise
•
Spindle rotates counter-clockwise
•
Spindle does not rotate
S
Spindle speed – (only when the spindle rotates)
rev/min
α1
Angular offset
Degrees
Z1
Transfer position (abs.)
ZR Position, feedrate reduction (abs or inc)
Position from which a reduced feedrate is used.
FR
Reduced feedrate
mm/rev
Fixed
stop
Travel to fixed stop
• Yes
The counter-spindle stops at a defined distance away from transfer position
Z1 and then traverses with a defined feedrate up to the fixed stop.
• No
The counter-spindle traverses to the transfer position Z1.
