Collision avoidance (only 840D sl)

11.1 Activating collision avoidance

Turning

666 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

Precondition

● Collision avoidance is setup and an active machine model is available.

● The setting "Collision avoidance" has been selected for the AUTO operating mode or for

the JOG and MDA operating modes.

Procedure

Select the "Machine" operating area

Press the <AUTO> key.

Press

the "Sim. rec." softkey.

Press the "Other views" and "Machine area" softkeys.

An active machine model is displayed for simultaneous recording.
