Managing programs
13.4 Creating a directory / program / job list / program list
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
747
● <Program>
Absolute or relative path specification of the program to be selected.
Examples:
– //NC/WCS.DIR/SHAFT.WPD/SHAFT1.MPF
– SHAFT2.MPF
● <Channel number>
Number of the NC channel in which the program is to be selected.
Example:
CH=2
● [DISK]
Optional parameter for programs that are not in the NC memory and are to be executed
"externally".
Example:
SELECT //remote/myshare/shaft3.mpf CH=1 DISK
Comment
Comments are identified in the job list by ";" at the start of the line or by round brackets.
Template
You can select a template from Siemens or the machine manufacturer when creating a new
job list.
Executing a workpiece
If the "Select" softkey is selected for a workpiece, the syntax of the associated job list is
checked and then executed. The cursor can also be placed on the job list for selection.
Procedure
1.
Select the "Program manager" operating area.
2.
Press the "NC" softkey, and in direct
ory "Workpieces" place the cursor
on the program for which you wish to create a job list.
3.
Press the "New" and "Any" softkeys.
The "Any New Program" window opens.
4.
Select entry
"Job list JOB" from the "Type" selection field and enter a
name and press the "OK" softkey.
