Setting up the machine

3.7 Settings for the measurement result log

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

Position the cursor to the log data field and select the required entry.

Position the cursor to the log archive field and press the softkey "Select

directory".

Navigate to the desired directory for the log archive.

Press the "OK" softkey and enter the name for the log file.

See also

Logging tool measurement results (Page 84)

Logging measurement results for the workpiece zero (Page 87)
