PERIODIC MAINTENANCE
3-13
5. Press the “SELECT” and “RESET” buttons
to select a cylinder.
The selected cylinder number appears on the
odometer, tripmeter and fuel reserve trip LCD.
• To decrease the selected cylinder number,
press the “RESET” button.
• To increase the selected cylinder number,
press the “SELECT” button.
6. After selecting the cylinder, simultaneously
press the “SELECT” and “RESET” buttons
for 2 seconds or more to execute the selec-
tion.
7. Change the CO adjustment volume by
pressing the “SELECT” and “RESET” but-
tons.
The CO adjustment volume appears on the
odometer, tripmeter and fuel reserve trip LCD.
• To decrease the CO adjustment volume,
press the “RESET” button.
• To increase the CO adjustment volume,
press the “SELECT” button.
8. Release the button to execute the selec-
tion.
9. Simultaneously press the “SELECT” and
“RESET” buttons to return to the cylinder
selection (step 5).
10. Turn the main switch to “OFF” to cancel the
CO adjustment mode.
EAS14B1099
CHECKING THE AIR INDUCTION SYSTEM
Refer to “CHECKING THE AIR INDUCTION
SYSTEM” on page 7-25.
EAS20961
REPLACING THE AIR FILTER ELEMENT
1. Remove:
• Rider seat
Refer to “GENERAL CHASSIS” on page
4-1.
2. Remove:
• Fuel tank
Refer to “FUEL TANK” on page 7-1.
3. Remove:
• Air filter case cover
Refer to “AIR FILTER CASE” on page 7-
5.
4. Check:
• Air filter element “1”
• Air filter seal
Damage → Replace.
• Replace the air filter element every 40000
km (24000 mi) of operation.
• The air filter needs more frequent service if
you are riding in unusually wet or dusty
areas.
5. Install:
• Air filter element
Align projection “a” of the air filter element to
the groove “b” of the air filter case cover and
install.
To Next Page
