VALVES AND VALVE SPRINGS
5-27
EAS24270
VALVES AND VALVE SPRINGS
* Silicon fluid
Removing the valves and valve springs
Order Job/Parts to remove Q’ty Remarks
Cylinder head Refer to “CYLINDER HEAD” on page 5-24.
1 Intake valve lifter 8
2 Intake valve pad 8
3 Intake valve cotter 16
4 Intake valve spring retainer 8
5 Intake valve spring 8
6 Intake valve 8
7 Intake valve stem seal 8
8 Intake valve spring seat 8
9 Intake valve guide 8
