GENERAL CHASSIS
4-10
EAS14B1029
REMOVING THE QUICK FASTENER
(SCREW TYPE)
To remove the quick fastener, turn its center
with a screwdriver counterclockwise, then pull
the fastener out.
EAS14B1030
INSTALLING THE QUICK FASTENER
(SCREW TYPE)
To install the quick fastener, turn its screw
counterclockwise so that it protrudes from the
fastener head, then insert the fastener into the
cover and turn the screw “a” clockwise in with
a screwdriver. Make sure that the screw is
flush with the fastener’s head.
EAS14B1031
REMOVING THE QUICK FASTENER (PUSH
TYPE)
To remove the quick fastener, push its center
with a screwdriver, then pull the fastener out.
EAS14B1032
INSTALLING THE QUICK FASTENER (PUSH
TYPE)
To install the quick fastener, push its pin so that
it protrudes from the fastener head, then insert
the fastener into the cover and push the pin “a”
in with screwdriver. Make sure that the pin is
flush with the fastener’s head.
EAS14B1103
REMOVING THE QUICK FASTENER (PULL
TYPE)
To remove the quick fastener, pull the pin “a”,
then pull the fastener out.
To Next Page
