THERMOSTAT
6-8
EAS26440
THERMOSTAT
Removing the thermostat
Order Job/Parts to remove Q’ty Remarks
Coolant
Drain.
Refer to “CHANGING THE COOLANT” on
page 3-32.
Fuel tank Refer to “FUEL TANK” on page 7-1.
Air filter case Refer to “AIR FILTER CASE” on page 7-5.
Throttle body
Refer to “THROTTLE BODIES” on page 7-
12.
1 Coolant reservoir cover 1
2 Coolant reservoir breather hose 1
3 Coolant reservoir hose 1
4 Coolant reservoir cap 1
5 Coolant reservoir tank 1
6 Thermostat outlet hose 1
7 Thermostat housing cover 1
8O-ring 1
9 Thermostat 1
10 Thermostat housing 1
11 Thermostat inlet hose 1
To Next Page
