AIR FILTER CASE
7-11
▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲
EAS14B1069
INSTALLING THE FUEL HOSE (PRIMARY
INJECTOR JOINT SIDE AND SECONDARY
INJECTOR JOINT SIDE)
1. Connect:
• Fuel hose (primary injector joint side and
secondary injector joint side)
ECA14B1033
When installing the fuel hose, make sure
that it is securely connected, and that the
fuel hose connector cover on the fuel hose
is in the correct position, otherwise the fuel
hose will not be properly installed.
• Install the fuel hose securely onto the sec-
ondary injector joint until a distinct “click” is
heard.
• To install the fuel hose onto the secondary
injector joint, slide the fuel hose connector
cover “1” on the end of the hose in the direc-
tion of the arrow shown.
To Next Page
