FRONT BRAKE
4-35
Disassembling the front brake calipers
Order Job/Parts to remove Q’ty Remarks
1 Brake pad clip 4
2 Brake pad pin 2
3 Brake pad spring 2
4 Brake pad kit 1
5 Brake caliper piston 6
6 Brake caliper piston dust seal 6
7 Brake caliper piston seal 6
8 Bleed screw 1
For installation, reverse the removal proce-
dure.
