REAR WHEEL
4-26
Removing the brake disc and rear wheel sprocket
Order Job/Parts to remove Q’ty Remarks
1 Rear brake disc 1
2 Rear wheel sprocket 1
3 Collar 2
4 Oil seal 1
5 Bearing 1
6 Rear wheel drive hub 1
7 Rear wheel drive hub damper 6
8 Rear wheel 1
For installation, reverse the removal proce-
dure.
