GENERAL CHASSIS
4-9
Disassembling the license plate/turn signal light assembly
Order Job/Parts to remove Q’ty Remarks
1 License plate/turn signal light stay 1
2 License plate/turn signal light stay plate 1
3Cover 1
4 Rear turn signal light 2
5 License plate light 1
6 Rear reflector 1
7 Mudguard 1
For installation, reverse the removal proce-
dure.
