Page 5-12 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 5 Maintenance and Assembly Drawings
Table 5-4. Print Mechanism (View 2)
Item Part Number Description Qty
1 HW30118 E-Ring Ext, 0.500 × 0.042 (only available in quantities of 25) 1
2 31336M RTU/MTU Pulley Maintenance Kit (203/300 dpi) 1
2 33094-6M RTU/MTU Pulley Maintenance Kit (600 dpi) 1
3 46909 Spacer, 0.75 × 0.52 × 0.36 1
4 HW30114 Flat Washer, 0.76 × 0.51 × 0.03 (Available in quantities of 25) 1
5 HW30115 Wave Washer, 0.740 × 0.520 × 0.080 (Available in quantities of 25) 1
6 HW06250 E-Ring EXT, 0.312 Yel (Available in quantities of 25) 1
7 HW40027 Torsion Spring (Available in quantities of 25) 1
8 HW30106 Crescent Ring, External, 0.312 (Available in quantities of 25) 1
9 HW30393-006 Screw, 8–-32 × 0.37 (Available in quantities of 25) 6
10 HW40193 Flat Washer, 0.406 × 0.172 × 0.048 (Available in quantities of 25) 3
11 30405-006 Cap Screw, 1/4–20 × 0.75 1
12 HW30466 Washer, 0.26 × 0.63 × 0.06 (Available in quantities of 25) 1
13 41253M Media Supply Spindle Maintenance Kit, 3–Inch (Optional) 1
13 41254M Media Supply Spindle Maintenance Kit, 40mm (Optional) 1
14 HW30239 Washer, Crescent, 0.415 × 323 × 0.062 (Available in quantities of 25) 1
15
41151M Spindle Ribbon Supply Maintenance Kit 1
16 41150M Enhanced Ribbon Take-Up Upgrade Kit 1
Bold=Part available for purchase
Italic=Part not available for purchase, listed and shown for reference only
