Page 5-26 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 5 Maintenance and Assembly Drawings
Table 5-12. Media Rewind Assembly
Item Part Number Description Qty
1 41383M Rewind Plate Assembly Maintenance Kit 1
2 47915M Lower Platen Pulley Maintenance Kit 1
3 30265 Idler Pulley 1
4 30207 Idler Pulley Shaft 1
5 45189-2 Rewind Drive Belt, 0.080P 235T (203 and 300 dpi) 1
5 45189-13 Rewind Drive Belt, 0.080P 245T (600 dpi) 1
6 HW30118 E-Ring, External 0.500 × 0.042 (only available in quantities of 25) 1
7 31336M MTU/RTU Pulley Maintenance Kit (203 and 300 dpi) 1
7 33094-6M Pulley MTU Maintenance Kit (600 dpi) 1
8 HW30114 Flat Washer, 0.76 × 0.51 × 0.03 (only available in quantities of 25) 1
9 HW30115 Wave Washer, 0.740 × 0.520 × 0.080 (only available in quantities of 25) 1
10 HW30393-006 Screw, 8–32 × 0.31 (only available in quantities of 25) 3
11 HW07435 Screw, 6–32 × 0.37 (only available in quantities of 100) 2
12 HW40193 Flat Washer, 0.406 × 0.172 × 0.048 (only available in quantities of 25) 1
13 46609-4M Take-Label Sensor Maintenance Kit (Includes Lower Sensor) 1
14 47155M Spindle Media Rewind Maintenance Kit 1
15 HW40193 Flat Washer, 0.406 × 0.172 × 0.048 (only available in quantities of 25) 3
16 HW30392-008 Screw, 6-32 × 0.25 (only available in quantities of 50) 2
17 02252 Crescent Ring, 0.25 2
18 40019 Plate, Roller Adjustment 1
19 HW30247 Flat Washer, 0.42 × 0.262 × 0.0740 (only available in quantities of 25) 1
20 HW30261 Flat Washer, 0.442 × 0.255 × 0.020 (only available in quantities of 25) 2
21 47601M Lower Platen Roller Maintenance Kit, 0.78 × 3.588 1
22 49688 Ball Bearing, 0.50 × 0.25 × 0.125 2
Bold=Part available for purchase
Italic=Part not available for purchase, listed and shown for reference only
