96 ZXP Series 9 Card Printer Service Manual P1086708-001
Operation
Messages
Warning Messages
Warnings alert the operator to action that should be taken—the printer will generally continue
operation.
WARNING
(Printer will still operate)
DESCRIPTION
BOTH LAMINATES LOW
Indicates that the Top Laminate cassette and the Bottom Laminate
cassette are low.
BOTTOM LAMINATE LOW
Indicates that the Bottom Laminate cassette is low (see “Loading the
Laminate” on page 99.
CLEAN FEEDER Indicates that the Feeder needs cleaning.
CLEAN FRONT CARD PATH
Indicates that the Front Card Path (Y-Drive Rollers) needs cleaning
(see Maintenance on page 69).
CLEAN LAM CARD PATH
Indicates that the Laminator Card Path needs cleaning (see
Maintenance on page 69).
CLEAN LAM MED ROLLERS
Indicates that the Laminator Media Feed Rollers need cleaning (see
Maintenance on page 69).
CLEAN LAM OVEN
Indicates that the Laminator Transfer Path (Heated Rollers) needs
cleaning (see Maintenance on page 69).
CLEAN SIDE CARD PATH
Indicates that the Side Card Path (X-Drive Rollers) needs cleaning
(see Maintenance on page 69).
CLEAN TRANSFER PATH
Indicates that the Transfer Path (Heated Rollers) needs cleaning (see
Maintenance on page 69).
PRINT RIBBON LOW
Indicates that the Print Ribbon spool is low (see “Loading Print
Ribbon” on page 19).
TOP LAMINATE LOW
Indicates that the Top Laminate cassette is low (see “Loading the
Laminate” on page 99).
TRANSFER FILM LOW
Indicates that the Transfer Film spool is low (see “Loading the
Transfer Film” on page 18).
Error Messages
Errors are displayed when a situation causes the printer to stop operating. Depending on the cause
of the error message, restarting the printer or clearing the displayed error may return the printer to
operational status; or the printer may require troubleshooting and repair.
See “OCP Error Messages” on page 129 for a list of the error messages, possible causes, and
possible solutions.
