P1086708-001 ZXP Series 9 Card Printer Service Manual 391
Replacement Procedures for the Laminator
Procedures: Bottom Thermopile Cable
Bottom Thermopile Cable
For replacement, use Kit CBL ASY LAM Thermopile BTM 105936G-531. Contact Zebra Customer
Service at +01 877-275-9327 for ordering information.
Step 1. Remove the bottom thermopile (see “Thermopiles (Top & Bottom)” on page 386).
Step 2. Locate the bottom thermopile cable (arrow below).
Step 3. Carefully slide the bottom thermopile cable out of the Laminator.
