Operation
Operator Control Panel (OCP)
Printer Menu Information
Info Menu
INFO Button
(Operating Mode Display)
Info Menu
PREV NEXT EXIT
LAM TEMPERATURE INFO *
Displays Settings: Top and Bottom temperature; and Current:
Top and Bottom temperature.
LAMINATOR ODOMETER *
Displays Unit on (# days), Top on (# days), Bottom on (#
days), # Laminated, # Processed.
* Applies to printer with attached laminator.
** Applies to printer with optional wireless upgrade.
TOP LAMINATE INFO * Displays P/N, Type, # Images, and % Remaining.
PRINTER INFO
Displays MCB FW Ver, HCB FW Ver, MAB FW Ver, and Mfr
Serial Number.
FILM INFO Displays Type, # Images, and % Remaining.
NETWORK INFO
Displays DHCP, IP, Mask, GW, and MAC.
PRINTHEAD USAGE
Displays Card Count and Printhead Lines.
REJECT BIN Displays Card Count.
RIBBON INFO
Displays Type, # Images, and % Remaining.
CONFIGURATION INFO
Displays RAM, Single or Dual Sided, and Options Installed:
Mag, Encoder, Laminator.
WIRELESS INFO **
Displays Settings: SSID, Channel Noise Floor, WEP, DHCP,
IP, Mask, GW, and MAC. Only applies to Printers with the
Wireless option installed.
TEMPERATURE INFO
Displays Settings: Top and Bottom temperature; and Current
Temperature: Top and Bottom.
WIRELESS STATISTICS **
Displays RX Bytes, Discards, TX Bytes, Discards, Errors; TX
Success, TX Retry, RX Success,
RX Duplicate, and RTS Success. Only applies to Printers
with the Wireless option installed.
BTM LAMINATE INFO * Displays Type, # Images, and % Remaining.
LAMINATOR INFO *
Displays LCB, MAB, LSN, Top installed (yes/no), Bottom
installed (yes/no).
CAL LUT INFO Displays Look-Up Table info for LUT1 and LUT2.
