Rockwell Automation Publication 2094-UM002G-EN-P - August 2016 103
Connect the Kinetix 6200 and Kinetix 6500 Drive System Chapter 5
Power Wiring Requirements
Wire must be copper with 75 °C (167 °F) minimum rating. Phasing of main
AC power is arbitrary and earth ground connection is required for safe and
proper operation.
For IPIM module power wiring requirements, refer to the Kinetix 6000M
Integrated Drive-Motor System User Manual, publication 2094-UM003
.
Refer to Power Wiring Examples on page 233
for interconnect diagrams.
Table 54 - IAM Power Wiring Requirements
IMPORTANT The National Electrical Code and local electrical codes take precedence
over the values and methods provided.
Bulletin 2094 Drive
Cat. No.
Description
Connects to Terminals Recommended
Wire Size
mm
2
(AWG)
Strip Length
mm (in.)
Torque Value
N•m (lb•in)
Pin Signal
2094-BC01-Mxx-M
2094-BC02-M02-M
DC bus
(1)
and
VAC input power
IPD-1
IPD-2
IPD-3
IPD-4
IPD-5
IPD-6
10…2.5
(8…14)
10
(0.38)
1.2…1.5
(10.6…13.2)
2094-BC04-M03-M
10…6
(8…10)
16
(0.63)
2.4…3.0
(21.6…26.5)
2094-BC07-M05-M 30 (3)
2094-BCxx-Mxx-M
Control input power
CPD-1 CTRL 2
4…2.5
(12…14)
10
(0.38)
0.5…0.6
(4.4…5.3)
CPD-2 CTRL 1
Contactor Enable
CED-1 CONT EN-
4…2.5
(12…14)
(2)
0.5…0.6
(4.4…5.3)
CED-2 CONT EN+
(1) DC common-bus connections (leader IAM to follower IAM module) should be kept as short as possible.
(2) The actual gauge of the contactor enable wiring depends on the system configuration. Consult your machine builder, the NEC, and applicable local codes.
ATTENTION: To avoid personal injury and/or equipment damage, make sure
installation complies with specifications regarding wire types, conductor
sizes, branch circuit protection, and disconnect devices. The National
Electrical Code (NEC) and local codes outline provisions for safely installing
electrical equipment.
ATTENTION: To avoid personal injury and/or equipment damage, make sure
motor power connectors are used for connection purposes only. Do not use
them to turn the unit on and off.
ATTENTION: To avoid personal injury and/or equipment damage, make sure
shielded power cables are grounded to prevent potentially high voltages on
the shield.
