Chapter 2 Plan the Kinetix 6200 and Kinetix 6500 Drive System Installation
Circuit Breaker/Fuse Options
The 2094-BCxx-Mxx-M and 2094-BMxx-M drive modules, and the
Kinetix 6000M integrated drive-motor system (2094-SEPM-B24-S IPIM
module and MDF-SBxxxxx IDM units) use internal solid-state motor short-
circuit protection and, when protected by suitable branch circuit protection,
are rated for use on a circuit capable of delivering up to 200,000 A (fuses) and
65,000 A (circuit breakers).
Table 7 - Control and DC-bus Circuit Protection Specifications
Input Power Circuit Protection (LIM)
The 2094-BL02 line interface module (LIM) contains supplementary
protection devices and, when protected by suitable branch circuit protection, is
rated for use on a circuit capable of delivering up to 5000 A. When this module
is used, protection on the line side of the LIM module is required. Fuses must
be class J or CC only.
The 2094-BLxxS and 2094-XL75S-Cx LIM modules contain branch circuit
rated devices suitable for use on a circuit capable of delivering up to 65,000 A
(400V-class).
Refer to the Line Interface Module Installation Instructions, publication
2094-IN005
, for power specifications and more information on using the LIM
module.
Refer to Input Power Circuit Protection (without LIM) on page 31
when your
drive system does not include the LIM module.
IAM Module
Cat. No.
Control Input Power DC-bus Power
Bussmann Fuse
(1)
Allen-Bradley® Circuit Breaker
(2)
(non-UL)
Bussmann Fuse Mersen Fuse
(3)
2094-BC01-MP5-S
FNQ-R-10 (10 A) or
FNQ-R-7.5 (7.5 A)
1492-SPM2D060 or
1492-SPM1D150
FWJ-20A14F DCT20-2
2094-BC01-M01-S
2094-BC02-M02-S FWJ-40A A70QS40-4
2094-BC04-M03-S FWJ-70A A70QS70-4
2094-BC07-M05-S FWJ-125A A70QS125-4
(1) Use FNQ-R-7.5 circuit breaker for higher single -cycle inrush current capability. This is recommended when the continuous control-power current exceeds 3.0 A.
(2) Use 1492-SPM1D150 circuit breaker for higher single -cycle inrush current capability. This is recommended when the continuous control-power current exceeds 3.0 A.
(3) Mersen fuses were formerly known as Ferraz Shawmut.
