Rockwell Automation Publication 2094-UM002G-EN-P - August 2016 23
Start Chapter 1
Catalog Number Explanation
Kinetix 6200 and Kinetix 6500 (Bulletin 2094) modular drive catalog
numbers and descriptions are listed in the tables below. All power modules are
compatible with the Kinetix 6200 and Kinetix 6500 control modules.
Table 2 - Kinetix 6200 and Kinetix 6500 Drive Catalog Numbers
Table 3 - Kinetix 6000 Drive Component Catalog Numbers
Integrated Axis Modules (460V) Cat. No.
IAM power module, 400V-class, 6 kW converter, 4 A (0-pk) inverter 2094-BC01-MP5-M
IAM power module, 400V-class, 6 kW converter, 9 A (0-pk) inverter 2094-BC01-M01-M
IAM power module, 400V-class, 15 kW converter, 15 A (0-pk) inverter 2094-BC02-M02-M
IAM power module, 400V-class, 28 kW converter, 30 A (0-pk) inverter 2094-BC04-M03-M
IAM power module, 400V-class, 45 kW converter, 49 A (0-pk) inverter 2094-BC07-M05-M
Axis Modules (460V)
AM power module, 400V-class, 4 A (0-pk) 2094-BMP5-M
AM power module, 400V-class, 9 A (0-pk) 2094-BM01-M
AM power module, 400V-class, 15 A (0-pk) 2094-BM02-M
AM power module, 400V-class, 30 A (0-pk) 2094-BM03-M
AM power module, 400V-class, 49 A (0-pk) 2094-BM05-M
Kinetix 6200 Control Modules
Control module, sercos interface, Safe Torque Off 2094-SE02F-M00-S0
Control module, sercos interface, Safe Speed Monitor 2094-SE02F-M00-S1
Kinetix 6500 Control Modules
Control module, EtherNet/IP network, Safe Torque Off 2094-EN02D-M01-S0
Control module, EtherNet/IP network, Safe Speed Monitor 2094-EN02D-M01-S1
Drive Components Cat. No.
Integrated power interface (IPIM) module, 400V-class, 15 kW, 24 A (rms) 2094-SEPM-B24-S
Kinetix 6000 shunt module, 200/400V-class, 200 W 2094-BSP2
Kinetix 6000 slot-filler module, 200/400V-class 2094-PRF
