Rockwell Automation Publication 2094-UM002G-EN-P - August 2016 287
Appendix E
Web Server Interface
The Kinetix 6200 and Kinetix 6500 drives support a web-server interface for
common status reporting and network configuration attributes. The web
server also supports the safety configuration for 2094-SE02F-M00-S1 and
2094-EN02D-M01-S1 control modules.
Overview
The web-server interface is accessed through an Ethernet connection between
the drive and your personal computer. The drive has a private IP address, with
the final octet determined by the drive node address or Ethernet address
(configured in the Logix Designer application>Axis Properties). For example,
with http://192.168.1.1, the IAM power module node address is 001.
Refer to Chapter 6
(for Sercos drives) or Chapter 7 (for EtherNet/IP drives)
for more information on setting the node address of your Kinetix 6200 servo
drive or Ethernet address of your Kinetix 6500 servo drive.
The web-server interface provides a Home page that displays the current status
of the safety configuration and buttons to lock/unlock the configuration, save
the configuration to a file, apply a specific configuration, and set an optional
password. Though optional, you can configure a password to help protect the
system configuration from unauthorized modifications. Use the Change Safety
Password page to change the password.
Topic Page
Overview 287
Home Category 289
Diagnostics Category 290
Fault Logs Category 300
Data Logs Category 301
Administrative Settings Category 302
Browse Power Rail Category 302
Safety Category 303
